INVT Goodrive 310-UL Series Operation Manual page 133

GD310-UL series VFD
Function
code
Rated frequency of
P02.02
asynchronous motor 1
Rated voltage of
P02.04
asynchronous motor 1
P04.00 Motor 1V/F curve setting
P04.01 Torque boost of motor 1
P04.02 Torque boost close of motor 1 0.0%–50.0% (rated frequency of motor 1)
P04.03 V/F frequency 1 of motor 1 0.00Hz–P04.05
P04.04 V/F voltage 1 of motor 1
P04.05 V/F frequency 2 of motor 1 P04.03– P04.07
P04.06 V/F voltage 2 of motor 1
P04.07 V/F frequency 3 of motor 1 P04.05–P02.02 or P04.05–P02.16
P04.08 V/F voltage 3 of motor 1
V/F slip compensation gain
P04.09
Vibration control factor at low
P04.10
frequency of motor 1
Vibration control factor at
P04.11
high frequency of motor 1
Vibration control threshold of
P04.12
P04.13 Motor 2 V/F curve setting
P04.14 Torque boost of motor 2
P04.15 Torque boost close of motor 2 0.0%–50.0% (rated frequency of motor 1)
P04.16 V/F frequency 1 of motor 2 0.00Hz–P04.05
P04.17 V/F voltage 1 of motor 2
Name
of motor 1
motor 1
Description
0.01Hz–P00.03 (max frequency)
0–1200V
0: Straight line V/F curve; applying to the
constant torque load
1: Multi-dots V/F curve
2: Torque step-down V/F curve (power of 1.3)
3: Torque step-down V/F curve (power of 1.7)
4: Torque step-down V/F curve (power of 2.0)
5: Customized V/F (V/F separation)
0.0%: (automatic)0.1%–10.0%
0.0%–110.0%
0.0%–110.0%
0.0%–110.0%
0.0–200.0%
0–100
0–100
0.00Hz–P00.03 (the max frequency)
0: Straight line V/F curve; applying to the
constant torque load
1: Multi-dots V/F curve
2: Torque step-down V/F curve (power of 1.3)
3: Torque step-down V/F curve (power of 1.7)
4: Torque step-down V/F curve (power of 2.0)
5: Customized V/F (V/F separation)
0.0%: (automatic) 0.1%–10.0%
0.0%–110.0%
-125-
Basic operation instruction
Default
value
60.00
Depend on
model
0
0.0%
20.0%
0.00Hz
0.0%
00.00Hz
0.0%
00.00Hz
0.0%
100.0%
10
10
30.00 Hz
0
0.0%
20.0%
0.00Hz
0.0%
