INVT Goodrive 310-UL Series Operation Manual page 23

GD310-UL series VFD
Serial No.
1 Keypad port
2 Upper cover
3
4
5
6
7
8 Control terminals
9 Main circuit terminals
10 Main circuit cable port Fix the main circuit cable
11 POWER light
12 Simple name plate
13 Lower cover
Name
Connect the keypad
Protect the internal parts and components
Keypad See Keypad operation procedure for detailed information
See Maintenance and hardware diagnostics for detailed
Cooling fan
information
Wiring port Connect to the control board and the drive board
Name plate See Product Overview for detailed information
Optional. The side cover will increase the protective degree
of the VFD. The internal temperature of the VFD will
Side cover
increase, too, so it is necessary to derate the VFD at the
same time
See Installation guidelines for detailed information
See Installation guidelines for detailed information
Power indicator
See Type designation key for detailed information
Protect the internal parts and components
Description
-15-
Product Overview
