INVT Goodrive 310-UL Series Operation Manual page 129

GD310-UL series VFD
Function
code
Keypad setting for upper
frequency of forward
P03.16
Keypad setting for upper
P03.17 frequency of reverse
Upper electromotion
P03.18
torque source
Upper braking torque
P03.19
Keypad setting of
P03.20
electromotion torque
Keypad setting of
P03.21
braking torque
Flux weakening
P03.22 coefficient in constant
Lowest flux weakening
point in constant power
P03.23
P03.24 Max. voltage limit
P03.25 Pre-exciting time
P17.32 Magnetic flux linkage
Name
upper-limit frequency
7: PROFIBUS/CANopen communication
setting upper-limit frequency
8: Ethernet communication setting upper-limit
frequency
9: Reserved
Note: Setting method 1–9, 100%
corresponds to the maximum frequency.
rotation Setting range: 0.00Hz–P00.03
(the max frequency)
rotation
0: Keypad setting upper-limit frequency
(P03.20 sets P03.18, P03.21 sets P03.19)
1: AI1
2: AI2
3: AI3
4: HDI
5: MODBUS communication
6: PROFIBUS/CANopen communication
source
7: Ethernet communication
8: Reserved
Note: setting mode 1–4, 100% corresponds
to three times of the motor current.
0.0–300.0% (rated current of the motor)
0.1–2.0
power zone
10%–100%
zone
0.0–120.0%
0.000–10.000s
0.0–200.0%
Description
-121-
Basic operation instruction
Default
value
60.00Hz
60.00Hz
0
0
180.0%
180.0%
0.3
20%
100.0%
0.300s
0
