INVT Goodrive 310-UL Series Operation Manual page 255

GD310-UL series VFD
Power conversion model
series
GD310-004G-4-UL
GD310-5R5G-4-UL
GD310-7R5G-4-UL
GD310-011G-4-UL
GD310-015G-4-UL
GD310-018G-4-UL
GD310-022G-4-UL
GD310-030G-4-UL
GD310-037G-4-UL
GD310-045G-4-UL
GD310-055G-4-UL
GD310-075G-4-UL
GD310-090G-4-UL
GD310-110G-4-UL
GD310-132G-4-UL
GD310-160G-4-UL
GD310-185G-4-UL
GD310-200G-4-UL
GD310-220G-4-UL
GD310-250G-4-UL
GD310-280G-4-UL
GD310-315G-4-UL
GD310-350G-4-UL
GD310-400G-4-UL
GD310-500G-4-UL
GD310-5R5P-4-UL
GD310-7R5P-4-UL
GD310-011P-4-UL
GD310-015P-4-UL
GD310-018P-4-UL
GD310-022P-4-UL
GD310-030P-4-UL
GD310-037P-4-UL
GD310-045P-4-UL
GD310-055P-4-UL
GD310-075P-4-UL
Max Prospective
line Isc
5kA
5kA
5kA
5kA
5kA
5kA
10kA
10kA
10kA
10kA
10kA
10kA
10kA
10kA
100kA
100kA
100kA
100kA
100kA
100kA
100kA
100kA
100kA
100kA
100kA
5kA
5kA
5kA
5kA
5kA
5kA
10kA
10kA
10kA
10kA
10kA
-247-
Peripheral options and parts
Fuse class type
CC
CC
T
T
T
T
T
T
T
T
T
T
T
T
/
/
/
/
/
/
/
/
/
/
/
CC
T
T
T
T
T
T
T
T
T
T
Fuse current rating
20A/600V
30A/600V
40A/600V
50A/600V
50A/600V
80A/600V
90A/600V
125A/600V
150A/600V
200A/600V
200A/600V
400A/600V
400A/600V
400A/600V
600A/600V
600A/600V
600A/600V
600A/600V
900A/600V
900A/600V
900A/600V
1500A/600V
1500A/600V
1500A/600V
1500A/600V
30A/600V
40A/600V
50A/600V
50A/600 V
80A/600V
90A/600V
125A/600V
150A/600V
200A/600V
200A/600V
200A/600V
