INVT Goodrive 310-UL Series Operation Manual page 81

GD310-UL series VFD
Function
Name
code
Lower output
P06.17
limit of AO1
Corresponding
P06.18 AO1 output of
lower limit
Upper output
P06.19
limit of AO1
Corresponding
P06.20 AO1 output of
upper limit
AO1 output
P06.21
filter time
Lower output
P06.22
limit of AO2
Corresponding
P06.23 AO2 output of
lower limit
Upper output
P06.24
limit of AO2
Corresponding
P06.25 AO2 output of
upper limit
AO2 output
P06.26
filter time
12: AI3 input value
13: High speed pulse HDI input value
14: MODBUS communication set value 1
15: MODBUS communication set value 2
16: PROFIBUS/CANopen communication set value 1
17: PROFIBUS/CANopen communication set value 2
18: Ethernet communication set value 1
19: Ethernet communication set value 2
20–21: Reserved
22: Torque current (relative to 3 times the rated
current of the motor)
23: Ramp reference frequency (with sign)
24–30: Reserved
The above function codes define the relative
relationship between the output value and analog
output. When the output value exceeds the range of
set maximum or minimum output, it will count
according to the low-limit or upper-limit output.
When the analog output is current output, 1mA
equals to 0.5V.
In different cases, the corresponding analog output
of 100% of the output value is different. For detailed
information, please refer to analog output
instructions in Chapter 7.
AO
10V (20mA)
0.0%
Setting range of P06.18: 0.00V–10.00V
Setting range of P06.19: P06.17–100.0%
Setting range of P06.20: 0.00V–10.00V
Setting range of P06.21: 0.000s–10.000s
Setting range of P06.22: -100.0%–P06.24
Setting range of P06.23: 0.00V–10.00V
Setting range of P06.24: P06.22–100.0%
Description
100.0%
-73-
Function parameter
Default
Modify
value
○
0.0%
○
0.00V
○
100.0%
○
10.00V
○
0.000s
○
0.0%
○
0.00V
○
100.0%
○
10.00V
○
0.000s
