GD310-UL series VFD

4.2.4 Single installation

Note: The minimum space of B and C is 100mm.

4.2.5 Multiple installations

Parallel installation
A
B
A
Note:
 Before installing the different sizes VFDs, please align their top position for the convenience of
later maintenance.
 The minimum space of B, D and C is 100mm.
A
B B
A
Figure 4-3 Single installation
D
Figure 4-4 Parallel installation
Warm air
Cold air
B
-19-
Installation guidelines
C
C
C
Warm air
C
Cold air
