INVT Goodrive 310-UL Series Operation Manual page 127

GD310-UL series VFD
Function
code
P00.00 Speed control mode
Motor parameter
P00.15
P02.00
Speed loop proportional
P03.00
Speed loop integral
P03.01
Low switching
P03.02
Speed loop proportional
P03.03
Speed loop integral time
P03.04
High switching
P03.05
Calculation
Calculation
Name
autotuning
Motor type 1
gain1
time1
frequency
gain 2
2
frequency
ACR
Exciting
current
ACR
Torque
current
Position
observing
Flux
observing
Park
Transfo
rmation
Description
0: SVC mode 0 (apply to AM and SM)
1: SVC mode 1 (applying to AM)
2: SVM control
0: No operation
1: Rotating autotuning
2: Static autotuning 1 (autotune totally)
3: Static autotuning 2 (autotune part of the
parameters)
0: Asynchronous motor
1: Synchronous motor
0–200.0
0.000–10.000s
0.00Hz–P03.05
0–200.0
0.000–10.000s
P03.02–P00.03 (the max frequency)
-119-
Basic operation instruction
Park
PWM
Transfo
Pulse
rmation
Voltage
detection
Clark
Current
Transfo
detection
rmation
Motor
Rectifier
bridge
Converting
bridge
Default
value
1
0
0
20.0
0.200s
5.00Hz
20.0
0.200s
10.00Hz
