GD310-UL series VFD
Function
code
Keypad setting for
P03.16 upper frequency of
forward rotation
Keypad setting for
P03.17 upper frequency of
reverse rotation
Upper electromotion
P03.18
torque source
Upper braking torque
P03.19
Keypad setting of
P03.20
electromotion torque
Keypad setting of
P03.21
braking torque
P17.09 Output torque
P17.15 Torque reference

7.6 Parameters of the motor

 Physical accident may occur if the motor starts up suddenly during autotune.
Please check the safety of surrounding environment of the motor and the load
before autotune.
 The power is still applied even the motor stops running during static autotune.
Please do not touch the motor until the autotune is completed, otherwise there
would be electric shock.
 Do not carry out the rotation autotune if the motor is coupled with the load,
please do not operate on the rotation autotune. Otherwise, misacts or damage
may occur to the VFD or the mechanical devices. When carry out autotune on
the motor which is coupled with load, the motor parameter won't be counted
correctly and misacts may occur. It is proper to de-couple the motor from the
load during autotune when necessary.
Name
0.00Hz–P00.03 (the max frequency)
0.00 Hz–P00.03 (the max frequency)
0: Keypad setting upper-limit frequency (P03.20
sets P03.18, P03.21 sets P03.19)
1: AI1
2: AI2
3: AI3
4: HDI
5: MODBUS communication
6: PROFIBUS/CANopen communication
source
7: Ethernet communication
8: Reserved
Note: setting mode 1–4, 100% corresponds to
three times of the motor current.
0.0–300.0% (rated motor current)
0.0–300.0% (rated motor current)
-250.0–250.0%
-300.0–300.0% (rated current of the motor)
Description
-129-
Basic operation instruction
Default
value
60.00 Hz
60.00 Hz
0
0
180.0%
180.0%
0.0%
0.0%
