GD310-UL series VFD
Function
code
P04.18 V/F frequency 2 of motor 2 P04.16– P04.20
P04.19 V/F voltage 2 of motor 2
P04.20 V/F frequency 3 of motor 2 P04.18– P02.02 or P04.18– P02.16
P04.21 V/F voltage 3 of motor 2
V/F slip compensation gain
P04.22
Vibration control factor at low
P04.23
frequency of motor 2
Vibration control factor at
P04.24
high frequency of motor 2
Vibration control threshold of
P04.25
Energy-saving operation
P04.26
Voltage setting
P04.27
P04.28 Keypad setting voltage
P04.29 Voltage increasing time
P04.30 Voltage decreasing time
P04.31 Maximum output voltage
P04.32 Minimum output voltage

7.5 Torque control

Goodrive310-UL series VFDs support two kinds of control mode: torque control and rotation speed
control. The core of rotation speed is that the whole control focuses on the stable speed and ensures
the setting speed is the same as the actual running speed. The max load should be in the range of the
torque limit. The core of torque control is that the whole control focuses on the stable torque and
ensures the setting torque is the same as the actual output torque. At the same time, the output
frequency is among the upper limit or the lower limit.
Name
of motor 2
motor 2
Description
0.0%–110.0%
0.0%–110.0%
0.0–200.0%
0–100
0–100
0.00Hz–P00.03 (the max frequency)
0: No action
1: Automatic energy-saving running
0: Keypad: the output voltage is determined
by P04.28.
1: AI1 ;
2: AI2;
3: AI3;
4: HDI;
5: Multi-step speed;
6: PID;
7: MODBUS communication;
8: PROFIBUS/CANopen communication;
9: Ethernet communication;
10: Reserved
0.0%–100.0% (rated motor voltage)
0.0–3600.0s
0.0–3600.0s
P04.32–100.0% (rated motor voltage)
0.0%–P04.31 (rated motor voltage)
-126-
Basic operation instruction
Default
value
0.00Hz
0.0%
0.00Hz
0.0%
100.0%
10
10
30.00Hz
0
0
100.0%
5.0s
5.0s
100.0%
0.0%
