INVT Goodrive 310-UL Series Operation Manual page 50

GD310-UL series VFD
Function
Name
code
B frequency
P00.08 command
reference
Combination
P00.09 of the setting
source
6: Multi-step speed running setting
The VFD runs at multi-step speed mode when
P00.06=6 or P00.07=6. Set P05 to select the current
running stage, and set P10 to select the current
running frequency.
The multi-step speed has the priority when P00.06 or
P00.07 does not equal to 6, but the setting stage can
only be the 1–15 stage. The setting stage is 1–15 if
P00.06 or P00.07 equals to 6.
7: PID control setting
The running mode of the VFD is process PID control
when P00.06=7 or P00.07=7. It is necessary to set
P09. The running frequency of the VFD is the value
after PID effect. See P09 for the detailed information
of the given source, given value, feedback source of
PID.
8: MODBUS communication setting
The frequency is set by MODBUS communication.
See P14 for detailed information.
9: PROFIBUS/CANopen communication setting
The frequency is set by PROFIBUS/ CANopen
communication. See P15 for the detailed information.
10: Ethernet communication setting (reserved)
11: Reserved
Note: A frequency and B frequency cannot set as the
same frequency given method.
0: Maximum output frequency, 100% of B frequency
setting corresponds to the maximum output
frequency
1: A frequency command, 100% of B frequency
setting corresponds to the maximum output
frequency. Select this setting if it needs to adjust on
the base of A frequency command.
0: A, the current frequency setting is A frequency
command
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A frequency
Description
-42-
Function parameter
Default
Modify
value
○
0
○
0
