INVT Goodrive 310-UL Series Operation Manual page 265

GD310-UL series VFD
Model
GD310-015P-4-UL
GD310-018P-4-UL
GD310-022P-4-UL
GD310-030P-4-UL
GD310-037P-4-UL
GD310-045P-4-UL
GD310-055P-4-UL
GD310-075P-4-UL
GD310-090P-4-UL
GD310-110P-4-UL
GD310-132P-4-UL
GD310-160P-4-UL
GD310-185P-4-UL
GD310-200P-4-UL
GD310-220P-4-UL
GD310-250P-4-UL
GD310-280P-4-UL
GD310-315P-4-UL
GD310-350P-4-UL
GD310-400P-4-UL
GD310-500P-4-UL
GD310-018G-6-UL
GD310-022G-6-UL
GD310-030G-6-UL
GD310-037G-6-UL
GD310-045G-6-UL
GD310-055G-6-UL
GD310-075G-6-UL
GD310-090G-6-UL
GD310-110G-6-UL
Model of
braking at 100% of
unit
torque (Ω)
DBU100H-060-4
DBU100H-110-4
DBU100H-160-4
DBU100H-220-4
DBU100H-320-4
DBU100H-400-4
TWO
DBU100H-320-4
TWO
DBU100H-400-4
DBU100H-110-6
DBU100H-160-6
Brake
The consumed power of
Resistor
braking resistor
10%
brake
braking
44 1.7
32 2
27 3
22 3
16 5
13 6
10 7
8 8
6.5 11
5.4 14
4.5 14
3.7 20
3.1 24
2.8 28
2.5 30
2.2 33
2.0 38
3.6*2 21*2
3.2*2 24*2
2.8*2 27*2
2.4*2 30*2
55 4
40.3 5
32.7 6
26.9 7
22.0 8
16.1 11
13.4 14
11.0 17
9.2 20
-257-
Peripheral options and parts
50% 80%
braking braking
8.3 13.2
11 18
14 22
17 26
23 36
28 44
34 54
41 66
56 90
68 108
83 132
99 158
120 192
139 222
150 240
165 264
188 300
105*2 168*2
118*2 189*2
132*2 210*2
150*2 240*2
17 27
23 36
28 44
34 54
41 66
56 90
68 108
83 132
99 158
Min
allowable
braking
resistance
(Ω)
31
23
19
17
17
11.7
6.4
4.4
3.2
2.2
1.8
2.2*2
2.2*2
10.0
6.9
