cease the damage to the rectifying components which are caused by supply net voltage transients
and harmonic waves of the loads. If the distance between the VFD and motor is longer than 100m,
contact INVT technical support.
Input reactor
Model
GD310-0R7G-2-UL
GD310-1R5G-2-UL
GD310-2R2G-2-UL
GD310-004G-2-UL
GD310-5R5G-2-UL
GD310-7R5G-2-UL
GD310-011G-2-UL
GD310-015G-2-UL
GD310-018G-2-UL
GD310-022G-2-UL
GD310-030G-2-UL
GD310-037G-2-UL
GD310-045G-2-UL
GD310-055G-2-UL
GD310-1R5G-4-UL
GD310-2R2G-4-UL
GD310-004G-4-UL
GD310-5R5G-4-UL
GD310-7R5G-4-UL
GD310-011G-4-UL
GD310-015G-4-UL
GD310-018G-4-UL
GD310-022G-4-UL
GD310-030G-4-UL
GD310-037G-4-UL
DC reactor
Input reactor
ACL2-2R2-4-UL
ACL2-004-4-UL
ACL2-004-4-UL
ACL2-7R5-4-UL
ACL2-011-4-UL
ACL2-015-4-UL
ACL2-022-4-UL
ACL2-030-4-UL
ACL2-037-4-UL
ACL2-045-4-UL
ACL2-055-4-UL
ACL2-075-4-UL
ACL2-110-4-UL
ACL2-110-4-UL
ACL2-1R5-4-UL
ACL2-2R2-4-UL
ACL2-004-4-UL
ACL2-5R5-4-UL
ACL2-7R5-4-UL
ACL2-011-4-UL
ACL2-015-4-UL
ACL2-018-4-UL
ACL2-022-4-UL
ACL2-030-4-UL
ACL2-037-4-UL
-249-
Peripheral options and parts
Output reactor
DC reactor
DCL2-2R2-4-UL
DCL2-004-4-UL
DCL2-004-4-UL
DCL2-7R5-4-UL
DCL2-015-4-UL
DCL2-015-4-UL
DCL2-022-4-UL
DCL2-030-4-UL
DCL2-037-4-UL
DCL2-045-4-UL
DCL2-055-4-UL
DCL2-075-4-UL
DCL2-090-4-UL
DCL2-132-4-UL
/
/
/
/
/
/
/
/
/
DCL2-030-4-UL
DCL2-037-4-UL
Output reactor
OCL2-2R2-4-UL
OCL2-004-4-UL
OCL2-004-4-UL
OCL2-7R5-4-UL
OCL2-011-4-UL
OCL2-015-4-UL
OCL2-022-4-UL
OCL2-030-4-UL
OCL2-037-4-UL
OCL2-045-4-UL
OCL2-055-4-UL
OCL2-075-4-UL
OCL2-110-4-UL
OCL2-110-4-UL
OCL2-1R5-4-UL
OCL2-2R2-4-UL
OCL2-004-4-UL
OCL2-5R5-4-UL
OCL2-7R5-4-UL
OCL2-011-4-UL
OCL2-015-4-UL
OCL2-018-4-UL
OCL2-022-4-UL
OCL2-030-4-UL
OCL2-037-4-UL
