INVT Goodrive 310-UL Series Operation Manual page 121

GD310-UL series VFD
Function
Name
code
ASR controller
P17.28
output
Magnetic pole
P17.29
angle of SM
Phase
compensation
P17.30
of SM
High-frequency
superimposed
P17.31
current of SM
Magnetic flux
P17.32
linkage
Exciting
current
P17.33
reference
Torque current
P17.34
reference
AC current
P17.35
Output torque
P17.36
Count value of
motor
P17.37
overload
P17.38 PID output
Wrong
download of
P17.39
parameters
The percentage of the rated torque of the relative
motor, display ASR controller output
Range: -300.0%–300.0% (rated motor current)
Display synchronous motor Magnetic pole angle
Range: 0.0–360.0
Display synchronous motor phase compensation
Range: -180.0–180.0
Display synchronous
Superimposed current
Range: 0.0%–200.0% (rated motor current)
Display the magnetic flux linkage of the motor.
Range: 0.0%–200.0%
Display the exciting current reference in the vector
control mode.
Range: -3000.0–3000.0A
Display the torque current reference in the vector
control mode.
Range: -3000.0–3000.0A
Display the value of inlet current in AC side.
Range: 0.0–5000.0A
Display the output torque. Positive value is in the
electromotion state, and negative is in the power
generating state.
Range: -3000.0Nm to 3000.0Nm
0–100 (100 reports OL1 fault)
-100.00–100.00%
0.00–99.99
Description
motor high-frequency
-113-
Function parameter
Default
Modify
value
●
0.0%
●
0.0
●
0.0
●
0.0
●
0.0%
●
0.0A
●
0.0A
●
0.0A
●
0.0Nm
●
0
●
0.00%
●
0.00
