Analog Output - INVT Goodrive 310-UL Series Operation Manual

GD310-UL series VFD
Function
code
P05.41
P05.42
Corresponding setting of the lower
P05.43
P05.44
P05.45 Corresponding middle setting of AI3 -100.0%–100.0%
P05.46
P05.47
P05.48
HDI high-speed pulse input function
P05.49
P05.50 Lower limit frequency of HDI
Corresponding setting of HDI low
P05.51
P05.52 Upper limit frequency of HDI
Corresponding setting of upper limit
P05.53
P05.54 HDI frequency input filter time

7.10 Analog output

Goodrive310-UL series VFDs have 2 analog output terminals (0–10V or 0–20mA) and 1 high speed
pulse output terminal. Analog output signal can be filtered and the maximum and minimum values can
be adjusted. The analog output signals can be proportional to motor speed, output frequency, output
current, motor torque, motor power, etc.
Name
AI2 input filter time
Lower limit of AI3
limit of AI3
Middle value of AI3
Upper limit of AI3
Corresponding setting of
the upper limit of AI3
AI3 input filter time
selection
frequency setting
frequency of HDI
Description
0.000s–10.000s
-10.00V–P05.44
-100.0%–100.0%
P05.42–P05.46
P05.44–10.00V
-100.0%–100.0%
0.000s–10.000s
0: Frequency setting input,
frequency setting source
1: Counter input, high-speed pulse
counter input terminals
2: Length counting input, length
counter input terminals
0.000kHz–P05.52
-100.0%–100.0%
P05.50–50.000kHz
-100.0%–100.0%
0.000s–10.000s
-143-
Basic operation instruction
Default
value
0.100s
-10.00V
-100.0%
0.00V
0.0%
10.00V
100.0%
0.100s
0
0.000kHz
0.0%
50.000kHz
100.0%
0.100s
