Name Plate - INVT Goodrive 310-UL Series Operation Manual

GD310-UL series VFD
Function
Mountable method
Temperature of the
running environment
Average non-fault time 2 years (25° C ambient temperature)
Braking unit
EMC filter
Others
Overvoltage category

3.4 Name plate

Wall and flange mounting
-10–50° C, derate 1% for every additional 1° C above 40° C
Cooling Air-cooling
Built-in for VFDs of 220V(≤15kW) and 460V(G-type≤30kW,
P-type≤37kW),
optional for VFDs of 220V(18.5–55kW) , 460V(G-type≥37kW,
P-type≥45kW), and 575V
The VFDs of 460V have built-in C3 filters: meet the degree
requirement of IEC61800-3 C3
For input voltage 220-240V: transient surge suppression shall
be installed on the line side of this equipment and shall be
rated 220V (phase to ground), 220V (phase to phase), suitable
for overvoltage categoryⅢ, and shall provide protection for a
rated impulse withstand voltage peak of 4kV.
For input voltage 323-480V: transient surge suppression shall
be installed on the line side of this equipment and shall be
rated 480V (phase to ground), 480V (phase to phase), suitable
for overvoltage category Ⅲ, and shall provide protection for a
rated impulse withstand voltage peak of 6kV.
For input voltage 323-480V: transient surge suppression shall
be installed on the line side of this equipment and shall be
rated 575V (phase to ground), 575V (phase to phase), suitable
for overvoltage category Ⅲ, and shall provide protection for a
rated impulse withstand voltage peak of 6kV.
Model: GD310-022G-4-UL
Power(Output): 22kW
Input: AC 3PH 380V-480V 56A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 45A 0Hz-400Hz
S/N:
Shenzhen INVT Electric Co.,Ltd
Figure 3-4 Name plate
Specification
Made in China
