P02 Group Motor 1 Parameters - INVT Goodrive20-UL VFD Series Operation Manual

Goodrive20-UL Series VFD
Function
Name
code
Start
P01.23
delay time
Delay of
the
P01.24
stopping
speed
0Hz
P01.25
output

P02 group Motor 1 parameters

Function
Name
code
Rated
power of
P02.01
asynchron
ous motor
Rated
frequency
P02.02 of
asynchron
ous motor
Rated
speed of
P02.03
asynchron
ous motor
Rated
voltage of
P02.04
asynchron
ous motor
Description
Setting range:
P01.21=1)
The function determines the brake release after
the running command is given, and the VFD is
in a stand-by state and wait for the delay time
set by P01.23
Setting range: 0.0–60.0s
Setting range: 0.0–100.0s
Select the 0Hz output of the VFD.
0: Output without voltage
1: Output with voltage
2: Output at the DC braking current
0.1–3000.0kW
0.01Hz–P00.03
1–60000rpm
0–1200V
0.0–3600.0s (valid
Description
-41-
Function parameters
Default
when
0.0s
0.0s
0
Default
Depend
on model
60.00Hz
Depend
on model
Depend
on model
Modify
○
○
○
Modify
◎
◎
◎
◎
