Goodrive3000 series medium voltage VFD
P02 group––Motor 1 parameters
Function
Name
code
P02.00 Motor 1 type
Select the type of motor 1.
Function
Name
code
Asynchronous motor
P02.01
1 rated power
Asynchronous motor
P02.02
1 rated frequency
Asynchronous motor
P02.03
1 rated speed
Asynchronous motor
P02.04
1 rated voltage
Asynchronous motor
P02.05
1 rated current
Set the parameters of the asynchronous motor under control.
To ensure control performance, please set values of P02.01–P02.05 correctly in accordance with the
parameters on the nameplate of the asynchronous motor.
Goodrive3000 VFDs provide parameter autotuning function from proper parameter setting of the
nameplate.
To ensure control performance, please configure the motor according to the standard motor of the VFD. If
the power is quite different from the standard motor, VFD control performance will decrease obviously.
Note: Reset the rated power of the motor (P02.01) to initialize the parameters of P02.02–P02.10.
Function
Name
code
Asynchronous
P02.06 motor 1 stator
resistor
Asynchronous
P02.07 motor 1 rotor
resistor
Description
0: Asynchronous motor
1: Reserved
Description
0.1–3000.0kW
0.01Hz–P00.03 (Max. frequency)
1–36000rpm
0–4000V
0.8–6000.0A
Description
0.001–65.535Ω
0.001–65.535Ω
-91-
Goodrive3000 inverter
Setting range Default
0–1 0
Setting range Default
Depends
0.1–3000.0
on model
0.01–P00.03 50.00Hz
Depends
1–36000
on model
Depends
0–4000
on model
Depends
0.8–6000.0
on model
Setting range Default
Depends
0.001–65.535
on model
Depends
0.001–65.535
on model
