Recommended Operating Conditions
This section lists the functional operation limits for AC and DC parameters for
Cyclone IV devices.
values expected from Cyclone IV E and Cyclone IV GX devices. All supplies must be
strictly monotonic without plateaus.
Table 1–3. Recommended Operating Conditions for Cyclone IV E Devices
Symbol
Supply voltage for internal logic,
1.2-V operation
(3)
V
CCINT
Supply voltage for internal logic,
1.0-V operation
Supply voltage for output buffers,
3.3-V operation
Supply voltage for output buffers,
3.0-V operation
Supply voltage for output buffers,
2.5-V operation
(3), (4)
V
CCIO
Supply voltage for output buffers,
1.8-V operation
Supply voltage for output buffers,
1.5-V operation
Supply voltage for output buffers,
1.2-V operation
Supply (analog) voltage for PLL
(3)
V
CCA
regulator
Supply (digital) voltage for PLL,
1.2-V operation
(3)
V
CCD_PLL
Supply (digital) voltage for PLL,
1.0-V operation
V Input voltage
I
V Output voltage
O
T Operating junction temperature
J
t Power supply ramp time
RAMP
Cyclone IV Device Handbook,
Volume 3
Table 1–3
Parameter
For commercial use
For industrial use
For extended temperature
For automotive use
Standard power-on reset
(POR)
Fast POR
and Table 1–4 list the steady-state voltage and current
(1), (2)
(Part 1 of 2)
Conditions
— 1.15
— 0.97
— 3.135
— 2.85
— 2.375
— 1.71
— 1.425
— 1.14
— 2.375
— 1.15
— 0.97
— –0.5
—
50 µs
(5)
(6)
50 µs
Chapter 1: Cyclone IV Device Datasheet
Operating Conditions
Min Typ Max
1.2 1.25
1.0 1.03
3.3 3.465
3 3.15
2.5 2.625
1.8 1.89
1.5 1.575
1.2 1.26
2.5 2.625
1.2 1.25
1.0 1.03
— 3.6
0 — V
CCIO
0 — 85
–40 — 100
–40 — 125
–40 — 125
— 50 ms
— 3 ms
