Chapter 3. Cyclone Iv Dynamic Reconfiguration; Glossary Of Terms - Altera Cyclone IV Device Handbook

November 2011
CYIV-52003-2.1
CYIV-52003-2.1
Cyclone
of the transceivers without powering down any part of the device. This chapter
describes and provides examples about the different modes available for dynamic
reconfiguration.
You can use the ALTGX_RECONFIG and ALTPLL_RECONFIG controller instance to
reconfigure the physical medium attachment (PMA) controls, physical coding
sublayer (PCS), multipurpose phase locked loops (PLLs), and general purpose PLLs.
This chapter contains the following sections:
■ "Glossary of Terms" on page 3–1
■ "Dynamic Reconfiguration Controller Architecture" on page 3–2
■ "Dynamic Reconfiguration Modes" on page 3–12
"Error Indication During Dynamic Reconfiguration" on page 3–36
■
"Functional Simulation of the Dynamic Reconfiguration Process" on page 3–37
■

Glossary of Terms

Table 3–1
Table 3–1. Glossary of Terms Used in this Chapter (Part 1 of 2)
Term
ALTGX_RECONFIG Instance
ALTGX Instance
ALTPLL_RECONFIG Instance
Logical Channel Addressing
