Altera Cyclone IV Device Handbook page 173

Chapter 8: Configuration and Remote System Upgrades in Cyclone IV Devices
Configuration
Table 8–4. Configuration Schemes for Cyclone IV GX Devices (EP4CGX30 [only for F484 package], EP4CGX50,
EP4CGX75, EP4CGX110, and EP4CGX150) (Part 2 of 2)
Configuration Scheme
JTAG-based configuration
(2)
Notes to Table 8–4:
(1) Configuration voltage standard applied to the V
(2) JTAG-based configuration takes precedence over other configuration schemes, which means the MSEL pin settings are ignored.
(3) Do not leave the MSEL pins floating. Connect them to V
Altera recommends connecting the MSEL pins to GND if your device is only using JTAG configuration.
1
Smaller Cyclone IV E devices or package options (E144 and F256 packages) do not
have the MSEL[3]pin. The AS Fast POR configuration scheme at 3.0- or 2.5-V
configuration voltage standard and the AP configuration scheme are not supported in
Cyclone IV E devices without the MSEL[3]pin. To configure these devices with other
supported configuration schemes, select MSEL[2..0]pins according to the MSEL
settings in
Table 8–5. Configuration Schemes for Cyclone IV E Devices
Configuration Scheme
AS
AP
PS
FPP
JTAG-based configuration
(2)
Notes to Table 8–5:
(1) Configuration voltage standard applied to the V
(2) JTAG-based configuration takes precedence over other configuration schemes, which means the MSEL pin settings are ignored.
(3) Do not leave the MSEL pins floating. Connect them to V
Altera recommends connecting the MSEL pins to GND if your device is only using JTAG configuration.
May 2013 Altera Corporation
MSEL3 MSEL2 MSEL1 MSEL0
(3) (3) (3)
supply of the bank in which the configuration pins reside.
CCIO
or GND. These pins support the non-JTAG configuration scheme used in production.
CCA
Table 8–5.
MSEL3 MSEL2 MSEL1
1 1 0
0 1 0
0 0 1
0 0 1
0 1 0
0 1 1
0 1 1
1 0 1
1 0 0
1 1 0
0 0 0
1 1 1
1 1 1
(3) (3) (3)
supply of the bank in which the configuration pins reside.
CCIO
or GND. These pins support the non-JTAG configuration scheme used in production.
CCA
POR Delay Configuration Voltage Standard (V)
(3)
—
MSEL0 POR Delay Configuration Voltage Standard (V)
1 Fast
0 Fast
0 Standard
1 Standard
1 Fast
0 Fast
1 Standard
1 Standard
0 Standard
0 Fast
0 Standard
0 Fast
1 Fast
(3)
—
8–9
(1)
—
(1)
3.3
3.0, 2.5
3.3
3.0, 2.5
3.3
1.8
3.3
3.0, 2.5
1.8
3.3, 3.0, 2.5
3.3, 3.0, 2.5
3.3, 3.0, 2.5
1.8, 1.5
—
