Table 1–25. PRBS, High and Low Frequency Patterns, and Channel Settings (Part 2 of 2)
Patterns Polynomial
Low
1111100000
(2)
Frequency
Notes to Table 1–25:
(1) Channel width refers to the What is the channel width? option in the General screen of the ALTGX MegaWizard Plug-In Manager. Based on the
selection, an 8 or 10 bits wide pattern is generated as indicated by a Yes (Y) or No (N).
(2) A verifier and associated rx_bistdone and rx_bisterr signals are not available for the specified patterns.
You can enable the serial loopback option to loop the generated PRBS patterns to the
receiver channel for verifier to check the PRBS patterns. When the PRBS pattern is
received, the rx_bisterr and rx_bistdone signals indicate the status of the verifier.
After the word aligner restores the word boundary, the rx_bistdone signal is driven
high when the verifier receives a complete pattern cycle and remains asserted until it
is reset using the rx_digitalreset port. After the assertion of rx_bistdone, the
rx_bisterr signal is asserted for a minimum of three rx_clkout cycles when errors
are detected in the data and deasserts if the following PRBS sequence contains no
error. You can reset the PRBS pattern generator and verifier by asserting the
tx_digitalreset and rx_digitalreset ports, respectively.
Cyclone IV Device Handbook,
Volume 2
8-bit Channel Width
Maximum
Channel
Data Rate
Width Word
(Gbps) for
of Alignment
F324 and
8 bits Pattern
Smaller
(1)
Packages
N — —
Chapter 1: Cyclone IV Transceivers Architecture
10-bit Channel Width
Maximum
Channel
Data Rate
Width Word
(Gbps) for
of Alignment
F484 and
10-bits Pattern
Larger
(1)
Packages
— Y —
February 2015 Altera Corporation
Self Test Modes
Maximum Maximum
Data Rate Data Rate
(Gbps) for (Gbps) for
F324 and F484 and
Smaller Larger
Packages Packages
2.5 3.125
