Chapter 8: Configuration and Remote System Upgrades in Cyclone IV Devices
Remote System Upgrade

Remote System Upgrade Registers

The remote system upgrade block contains a series of registers that stores the
configuration addresses, watchdog timer settings, and status information.
lists these registers.
Table 8–22. Remote System Upgrade Registers
Register
This register is accessible by the logic array and allows the update, status, and control registers to be written
Shift and sampled by user logic. Write access is enabled in remote update mode for factory configurations to allow
register writing to the update register. Write access is disabled for all application configurations in remote update
mode.
This register contains the current configuration address, the user watchdog timer settings, one option bit for
Control checking early CONF_DONE, and one option bit for selecting the internal oscillator as the startup state machine
register clock. During a read operation in an application configuration, this register is read into the shift register. When
a reconfiguration cycle is started, the contents of the update register are written into the control register.
This register contains data similar to that in the control register. However, it can only be updated by the factory
Update configuration by shifting data into the shift register and issuing an update operation. When a reconfiguration
register cycle is triggered by the factory configuration, the control register is updated with the contents of the update
register. During a read in a factory configuration, this register is read into the shift register.
This register is written by the remote system upgrade circuitry on every reconfiguration to record the cause of
Status
the reconfiguration. This information is used by the factory configuration to determine the appropriate action
register
following a reconfiguration. During a capture cycle, this register is read into the shift register.
The control and status registers of the remote system upgrade are clocked by the
10-MHz internal oscillator (the same oscillator that controls the user watchdog timer)
or the CLKUSR. However, the shift and update registers of the remote system upgrade
are clocked by the maximum frequency of 40-MHz user clock input (RU_CLK). There is
no minimum frequency for RU_CLK.
Remote System Upgrade Control Register
The remote system upgrade control register stores the application configuration
address, the user watchdog timer settings, and option bits for a application
configuration. In remote update mode for the AS configuration scheme, the control
register address bits are set to all zeros (24'b0) at power up to load the AS factory
configuration. In remote update mode for the AP configuration scheme, the control
register address bits are set to 24'h010000 (24'b1 0000 0000 0000 0000) at power up to
load the AP default factory configuration. However, for the AP configuration scheme,
you can change the default factory configuration address to any desired address using
the APFC_BOOT_ADDR JTAG instruction. Additionally, a factory configuration in remote
update mode has write access to this register.
