Chapter 1: Cyclone IV Transceivers Architecture
Transceiver Clocking Architecture

Bonded Channel Configuration

In bonded channel configuration, the low-speed clock for the bonded channels share a
common bonded clock path that reduces clock skew between the bonded channels.
The phase compensation FIFOs in bonded channels share a set of pointers and control
logic that results in equal FIFO latency between the bonded channels. These features
collectively result in lower channel-to-channel skew when implementing
multi-channel serial interface in bonded channel configuration.
In a transceiver block, the high-speed clock for each bonded channels is distributed
independently from one of the two multipurpose PLLs directly adjacent to the block.
The low-speed clock for bonded channels is distributed from a common bonded clock
path that selects from one of the two multipurpose PLLs directly adjacent to the block.
Transceiver channels for devices in F484 and larger packages support additional
clocking flexibility for ×2 bonded channels. In these packages, the ×2 bonded channels
support high-speed and low-speed bonded clock distribution from PLLs beyond the
two multipurpose PLLs directly adjacent to the block.
low-speed clock sources for the bonded channels.
Table 1–10. High- and Low-Speed Clock Sources for Bonded Channels in Bonded Channel
Configuration
F324 and smaller
F484 and larger
Note to
(1) GXBL1 is not available for transceivers in F484 package.
1
When implementing ×2 bonded channel configuration in a transceiver block,
remaining channels 2 and 3 are available to implement other non-bonded channel
configuration.
