CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.5.2

(Save/Load:) Load

Load Config from Loc: 9
11:02:43
Using Loc: 9 as the example: If Load is selected and there is a configuration stored at the selected
location, what displays is similar to the preceding example. Note that the stored configuration is
identified with a date and time stamp.
If the selected location contains no data, what displays is similar to the next example:
Load Config from Loc: 9
Empty
Select the location from where the current configuration is to be loaded using the
then press
ENTER
If the selected location contains valid data, what displays is similar to the following example:
New Config has been
Loaded from Loc #
Press or
ENTER
If the selected location contains invalid data, what displays is similar to the next example:
Warning! Loc 9 Contains
No Data!
Press or
ENTER
5.3.6

SELECT: Util (Utility)

UTIL: RT-Clk Ref ID
Display Firmware FAST
Select a submenu from the Util: menu branch – RT-Clk, Ref, ID, Display, Firmware, or FAST
– using the
5.3.6.1

(UTIL:) RT-Clk

Edit Real-Time Clock:
10:23:51 23/05/06 (
Edit the time and date settings of the real-time clock. Use the
Use the arrow keys to change the value of that digit, then press
Note: In accordance with international convention, the date is shown in DAY/MONTH/YEAR
format.
05/08/05 (
( E)
. There are 10 locations numbered 0 through 9.
(E)
to return to the previous menu.
CLEAR
(E)
to return to the previous menu.
CLEAR
arrow keys, then press
ENTER
E)
.
E)
5–50
Revision 11
MN/CDM710.IOM
arrow keys,
arrow keys to select the digit.
.
ENTER
