A.3.2 Chassis Power
Chassis Description
600 Chassis with Installation
Kit Steel Chassis, Front
Loading, "V" Steel Card
Guides, CE Marked
800 Chassis with Installation
Kit, Steel Chassis, Front and
Rear Loading, "V" Steel Card
Guides, CE Marked
900 Chassis with Installation
Kit, Power-Enhanced, Steel
Chassis, Top and Bottom
Front Loading, "V" Steel
Card Guides, CE Marked
A.3.3 Environment
A.3.3.1 Ambient Temperature and Humidity
Ambient temperature and humidity as per GR-63-CORE R4-6 and R4-7.
Temperature
Operate
o
0 to 50 C
o
32 to 122 F
Rate of temperature change
Ambient refers to conditions at a location 1.5 m (59 in) above the floor and 400 mm (15.8 in)
in front of the equipment. Short-term refers to a period of not more than 96 consecutive hours
and a total of not more than 15 days in 1year. This refers to a total of 360 hours in any given
year, but, no more than 15 occurrences during that 1 year period.
A.3.3.2 Altitude
As per GR-63-CORE R4-8. Functional within the limits specified in the table above when
installed at elevations between 60 m (197 ft.) below sea level and 1800 m (5905 ft.) above sea
level. As per O4-10. Functional within the limits specified in the table above when installed
at elevations between 1800 m (5905 ft.) and 4000 m (13,123 ft.) above sea level.
A-10
AC Power (50-60 Hz)
Model
Number
110 VAC
891630 90 VAC
to 135
VAC
891830 90 VAC
to 135
VAC
891930 115 VAC
104 to
135 VAC
o o
C / F
Short Term Storage
o o
-5 to 50 C -20 to 80
o o
23 to 122 F -4 to 176
o
30 C/hr (54
DC Power
220 VAC -48 VDC
175 VAC -40 VDC
to 264 to -60
VAC VDC
175 VAC -40 VDC
to 264 to -60
VAC VDC
175 VAC -40 VDC
to 264 to -60
VAC VDC
Operate
0 to 95% relative
C
humidity, non
F
condensing
o
F/hr)
Model No.
Power
Consumption
24 VDC Watts
+18 VDC 125 (typical)
to 35 300 W
VDC (maximum)
+18 VDC 125 (typical)
to 35 300 W
VDC (maximum)
+18 VDC 125 (typical)
to 35 500 W
VDC (maximum)
Humidity
Short Term
5 - 90 (not to exceed
0.024 kb H O/kg dry
2
air)
Reference Guide
