- Page 1 Zhone zNID 24xx Series Zhone zNID 24xx Series Hardw rdw are are Installation Installation Guide Guide For software version 2.4 For software version 2.4 December 2011 December 2011 Document Part Number: 830-03747-01 Document Part Number: 830-03747-01...
- Page 2 Inc. Bitstorm, EtherXtend, EZ Touch, IMACS, MALC, MXK, Raptor, SLMS, Z-Edge, Zhone, ZMS, zNID and the Bitstorm, EtherXtend, EZ Touch, IMACS, MALC, MXK, Raptor, SLMS, Z-Edge, Zhone, ZMS, zNID and the Zhone logo are Zhone logo are trademarks of Zhone Technologies, Inc.
- Page 3 Inc. Bitstorm, EtherXtend, EZ Touch, IMACS, MALC, MXK, Raptor, SLMS, Z-Edge, Zhone, ZMS, zNID and the Bitstorm, EtherXtend, EZ Touch, IMACS, MALC, MXK, Raptor, SLMS, Z-Edge, Zhone, ZMS, zNID and the Zhone logo are Zhone logo are trademarks of Zhone Technologies, Inc.
-
Page 4: Table Of Contents
C C A AB B L L E E OF ONTENTS ONTENTS Ab Abou out Th t This is Gui Guide ..............................................5 5 Style and notation co Style a nd notation co nventions nventions ................5 ................5 Typographical conventions..................6... - Page 5 Table of Contents Table of Contents C C ha hapte pter 2 z z N N I I D D 2 2 4 4 xx xx I I nsta nstalla llation tion ..................35 ..................35 Install Install the zNI the zNID D ......................35 ......................35 Installation precautions Installation...
- Page 6 A A T T G G BOUT BOUT H H I I S S UIDE UIDE This guide is intended for use by This guide is intended for use by installation technicians, system installation technicians, system administrators, or network administrators. It explains how to install the zNID administrators, or network administrators.
-
Page 7: Typographical Conventions
About This Guide WARNING! A warning alerts users to conditions or actions that could lead to injury caused by a laser. AVERTISSEMENT ! Un avertissement avertit les utilisateurs au sujet d'états ou d'actions qui pourraient entraîner des blessures causées par un laser. WARNING! This icon warns the user that metal surfaces can become hot to touch. -
Page 8: Related Documentation
Refer to the release notes for software installation information and for changes in features and functionality of the product (if any). Acronyms The following acronyms are related to Zhone products and may appear throughout this manual: Table 1: Acronyms and their descriptions Acro ny m... -
Page 9: Contacting Global Service And Support
Wireless local area network (trademark of Wi-Fi alliance) Voice Activity Detection VOIP Voice over IP zNID Zhone Network Interface Device Zhone Management System Contacting Global Service and Support Support for this product is provided by your Internet service provider zNID Hardware Installation Guide... -
Page 10: Fcc Statement
FCC Statement FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 11 About This Guide • Consulter le détaillant ou un technicien de radio/télévision pour obtenir de l'aide. Précaution FCC : Tous les changements ou modifications non expressément approuvés par la partie re sponsable de la conformité pourraient rendre nul le droit d'usage de l'appareil par l'utilisateur. Ce dispositif est conforme à...
- Page 12 CE compliance cerfications has been obtained for the following equipment: • ZNID-GPON-2402-XXX • ZNID-GPON-2403-XXX • ZNID-GPON-2424-XXX • ZNID-GPON-2425-XXX • ZNID-GPON-2426-XXX • ZNID-GPON-2427-XXX • ZNID-GE-2402-XXX • ZNID-GE-2424-XXX • ZNID-GE-2426-XXX The xxx suffix, 2-3 alphanumeric characters identify the sales re gion or specific customer with customized LOGO or software.
-
Page 13: Laser Safety Instructions
Laser Safety Instru ctio ns Zhone equipment and associated optical test sets use laser sources that emit light energy into fiber cables. This energy is within the red (visible) and infrared (invisible) regions of the electromagnetic spectrum. -
Page 14: Instructions De Sécurité Relatives Au Laser
Instruc tio ns de sécurit é relatives au laser Le matériel de Zhone et les ensembles de tests optiques associés utilisent des sources de laser qui émettent de l'énergie lumineuse dans les câbles optiques. -
Page 15: General Instructions
About This Guide WARNING! AVERTISSEMENT ! Ne regardez jamais dans une fibre optique active ou une ouverture de connecteur de fibre optique d'un appareil actif ou sous tension. Remarque : Lorsque vous travaillez avec des fibres optiques, prenez ces précautions : •... -
Page 16: Instructions Générales
Important Safety Instructions • When installed in the final configuration, the product must comply with the applicable Safety Standards and regulatory requirements of the country in which it is installed. If necessary, consult with the appropriate regulatory agencies and inspection authorities to ensure compliance. •... -
Page 17: Canada
About This Guide EMI Precautions Canada This Class B digital apparatus meets all requirements of the Canadian interference-causing equipment regulations. Cet appareil numérique de la classe B respecte toutes les exigences du règlement sur le matérial brouilleur du Canada. zNID Hardware Installation Guide... -
Page 18: Overview
GPON ONTs which are standards based Consumer Premises Equipment (CPE) designed for advanced triple-play deployments. The indoor models in Zhone's zNID product line of ONT's provide a lower cost alternative to outdoor ONT solutions. The small package contains many features including QoS, VoIP, and multicast video support. - Page 19 Zhone's Voice Gateway to traditional Class 5 TDM switches, while both MGCP and SIP are supported for direct connection to a VoIP Softswitch. This flexibility allows Zhone's 42xx, 9xxx and 24xx Series ONTs to work in nearly all Telco networks, with interoperability support for a broad array of Softswitches.
- Page 20 Overview zNID 24xx series components The zNID 24xx series indoor ONTs provide a variety of interfaces for triple play deployments. These indoor units may be mounted to a wall or placed on a desktop. Figure 1: The interfaces, displ ays and button s for the zNID 24xx Depending upon the zNID model selected, the interfaces on the zNID can include: •...
