OHSU Card User Screens and Settings

15.4 OHSU Card User Screens and Settings
The OHSU Cards permit configuration and operation through use of several user screens and
optional settings.

15.4.1 OHSU Card Main Screen

You must configure the OHSU Card ports for operation. Configuration can be performed from
the OHSU Card Main Screen, which is shown in Figure 15-3. For the four-port card, four ports
are displayed instead of two. To access that screen, highlight the desired card in the System
Main Screen and press <Enter>.
The bottom highlighted line on this screen lists several actions you can perform from the
screen. To perform an operation, simply press the uppercase letter associated with the desired
action. For example, to save your option settings, type "s". Table 15-1 lists the actions you can
perform.
15-4
Figure 15-3.Typical OHSU Card Main Screen
Model No.
OHSU-4P Card
Data Cards
