Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 PUy: Port B pull-up bit y (y=0..15)
When set, this bit activates the pull-up on PB[y] when APC bit is set in PWR_CR3 register.
The pull-up is not activated if the corresponding PDy bit is also set.
5.4.11
Power Port B pull-down control register (PWR_PDCRB)
Address offset: 0x2C.
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
PWRRST bit in the RCC_APB1RSTR1 register.
Access: Additional APB cycles are needed to access this register vs. a standard APB
access (3 for a write and 2 for a read).
31
30
29
Res.
Res.
Res.
Res.
15
14
13
PD15
PD14
PD13
PD12
rw
rw
rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:5 PDy: Port B pull-down bit y (y=5..15)
When set, this bit activates the pull-down on PB[y] when APC bit is set in PWR_CR3 register.
Bit 4 Reserved, must be kept at reset value.
Bits 3:0 PDy: Port B pull-down bit y (y=0..3)
When set, this bit activates the pull-down on PB[y] when APC bit is set in PWR_CR3 register.
5.4.12
Power Port C pull-up control register (PWR_PUCRC)
Address offset: 0x30.
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
PWRRST bit in the RCC_APB1RSTR1 register.
Access: Additional APB cycles are needed to access this register vs. a standard APB
access (3 for a write and 2 for a read).
28
27
26
25
Res.
Res.
Res.
12
11
10
9
PU11
PU10
PU9
rw
rw
rw
rw
28
27
26
25
Res.
Res.
Res.
12
11
10
9
PD11
PD10
PD9
rw
rw
rw
rw
DocID024597 Rev 5
24
23
22
21
Res.
Res.
Res.
Res.
8
7
6
5
PU8
PU7
PU6
PU5
rw
rw
rw
rw
24
23
22
21
Res.
Res.
Res.
Res.
8
7
6
5
PD8
PD7
PD6
PD5
rw
rw
rw
rw
Power control (PWR)
20
19
18
17
Res.
Res.
Res.
Res.
4
3
2
1
PU4
PU3
PU2
PU1
rw
rw
rw
rw
20
19
18
17
Res.
Res.
Res.
Res.
4
3
2
1
Res.
PD3
PD2
PD1
rw
rw
rw
16
Res.
0
PU0
rw
16
Res.
0
PD0
rw
