Flexible static memory controller (FSMC)
NOR Flash memory, 16-bit multiplexed I/Os
FMC signal name
CLK
A[25:16]
AD[15:0]
NE[x]
NOE
NWE
NL(=NADV)
NWAIT
The maximum capacity is 512 Mbits.
PSRAM/SRAM, non-multiplexed I/Os
FMC signal name
CLK
A[25:0]
D[15:0]
NE[x]
NOE
NWE
NL(= NADV)
NWAIT
NBL[1:0]
The maximum capacity is 512 Mbits.
PSRAM, 16-bit multiplexed I/Os
FMC signal name I/O
CLK
A[25:16]
AD[15:0]
424/1830

Table 68. 16-bit multiplexed I/O NOR Flash memory

I/O
O
O
16-bit multiplexed, bidirectional address/data bus (the 16-bit address
I/O
A[15:0] and data D[15:0] are multiplexed on the databus)
O
O
O
Latch enable (this signal is called address valid, NADV, by some NOR
O
I

Table 69. Non-multiplexed I/Os PSRAM/SRAM

I/O
O Clock (only for PSRAM synchronous access)
O
I/O
O Chip Select, x = 1..4 (called NCE by PSRAM (Cellular RAM i.e. CRAM))
O
O
O Address valid only for PSRAM input (memory signal name: NADV)
I
O Byte lane output. Byte 0 and Byte 1 control (upper and lower byte enable)

Table 70. 16-Bit multiplexed I/O PSRAM

O
O
16-bit multiplexed, bidirectional address/data bus (the 16-bit address
I/O
A[15:0] and data D[15:0] are multiplexed on the databus)
