Bits 31:0 KEYR4[31:0]: Data output register (key [159:128])
Same description as AES_KEYR0 for the key[159:128].
28.14.14 AES key register 5 (AES_KEYR5) (key[191:160])
Address offset: 0x34
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 KEYR5[31:0]: Data output register (key [191:160])
Same description as AES_KEYR0 for the key[191:160].
28.14.15 AES key register 6 (AES_KEYR6) (key[223:192])
Address offset: 0x38
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 KEYR6[31:0]: Data output register (key [223:192])
Same description as AES_KEYR0 for the key[223:192].
28.14.16 AES key register 7 (AES_KEYR7) (MSB: key[255:224])
Address offset: 0x3C
Reset value: 0x0000 0000
Advanced encryption standard hardware accelerator (AES)
27 26 25 24
KEYR431:16]
rw rw rw rw
11 10 9 8
rw rw rw rw
27 26 25 24
KEYR5[31:16]
rw rw rw rw
11 10 9 8
rw rw rw rw
27 26 25 24
KEYR631:16]
rw rw rw rw
11 10 9 8
rw rw rw rw
