Analog-to-digital converters (ADC)
Bits 7:6 JEXTEN[1:0]: External Trigger Enable and Polarity Selection for injected channels
Note: Software is allowed to write these bits at any time, once the ADC is enabled (ADEN=1).
Bits 5:2 JEXTSEL[3:0]: External Trigger Selection for injected group
Note: Software is allowed to write these bits at any time, once the ADC is enabled (ADEN=1).
Bits 1:0 JL[1:0]: Injected channel sequence length
Note: Software is allowed to write these bits at any time, once the ADC is enabled (ADEN=1).
18.6.17 ADC offset register (ADC_OFRy) (y=1..4)
Address offset: 0x60, 0x64, 0x68, 0x6C
Reset value: 0x0000 0000
31 30 29 28
OFFSETy
OFFSETy_CH[4:0]
_EN
rw rw rw rw
15 14 13 12
Res. Res. Res. Res.
602/1830
These bits are set and cleared by software to select the external trigger polarity and enable
the trigger of an injected group.
00: If JQDIS=0 (queue enabled), Hardware and software trigger detection disabled
00: If JQDIS=1 (queue disabled), Hardware trigger detection disabled (conversions can be
launched by software)
01: Hardware trigger detection on the rising edge
10: Hardware trigger detection on the falling edge
11: Hardware trigger detection on both the rising and falling edges
If JQM=1 and if the Queue of Context becomes empty, the software and hardware
triggers of the injected sequence are both internally disabled (refer to
Queue of context for injected
These bits select the external event used to trigger the start of conversion of an injected
group:
0000: Event 0
0001: Event 1
0010: Event 2
0011: Event 3
0100: Event 4
0101: Event 5
0110: Event 6
0111: Event 7
...
1111: Event 15
These bits are written by software to define the total number of conversions in the injected
channel conversion sequence.
00: 1 conversion
01: 2 conversions
10: 3 conversions
11: 4 conversions
27 26 25
Res.
rw rw
11 10 9
rw rw rw
conversions)
24 23 22
Res. Res. Res.
8 7 6
OFFSETy[11:0]
rw rw rw
DocID024597 Rev 5
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
rw rw rw rw
RM0351
Section 18.4.21:
17 16
Res. Res.
1 0
rw rw
