RM0351
Bit 10 APC: Apply pull-up and pull-down configuration
Bit 9 Reserved, must be kept at reset value.
Bit 8 RRS: SRAM2 retention in Standby mode
Bits 7:5 Reserved, must be kept at reset value.
Bit 4 EWUP5: Enable Wakeup pin WKUP5
Bit 3 EWUP4: Enable Wakeup pin WKUP4
Bit 2 EWUP3: Enable Wakeup pin WKUP3
Bit 1 EWUP2: Enable Wakeup pin WKUP2
Bit 0 EWUP1: Enable Wakeup pin WKUP1
5.4.4

Power control register 4 (PWR_CR4)

Address offset: 0x0C
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
the PWRRST bit in the RCC_APB1RSTR1 register.
Access: Additional APB cycles are needed to access this register vs. a standard APB
access (3 for a write and 2 for a read).
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
When this bit is set, the I/O pull-up and pull-down configurations defined in the PWR_PUCRx
and PWR_PDCRx registers are applied. When this bit is cleared, the PWR_PUCRx and
PWR_PDCRx registers are not applied to the I/Os.
0: SRAM2 is powered off in Standby mode (SRAM2 content is lost).
1: SRAM2 is powered by the low-power regulator in Standby mode (SRAM2 content is kept).
When this bit is set, the external wakeup pin WKUP5 is enabled and triggers a wakeup from
Standby or Shutdown event when a rising or a falling edge occurs.The active edge is
configured via the WP5 bit in the PWR_CR4 register.
When this bit is set, the external wakeup pin WKUP4 is enabled and triggers a wakeup from
Standby or Shutdown event when a rising or a falling edge occurs. The active edge is
configured via the WP4 bit in the PWR_CR4 register.
When this bit is set, the external wakeup pin WKUP3 is enabled and triggers a wakeup from
Standby or Shutdown event when a rising or a falling edge occurs. The active edge is
configured via the WP3 bit in the PWR_CR4 register.
When this bit is set, the external wakeup pin WKUP2 is enabled and triggers a wakeup from
Standby or Shutdown event when a rising or a falling edge occurs. The active edge is
configured via the WP2 bit in the PWR_CR4 register.
When this bit is set, the external wakeup pin WKUP1 is enabled and triggers a wakeup from
Standby or Shutdown event when a rising or a falling edge occurs. The active edge is
configured via the WP1 bit in the PWR_CR4 register.
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. Res. VBRS
rw
24 23 22
Res. Res. Res.
8 7 6
VBE Res. Res.
rw
DocID024597 Rev 5
Power control (PWR)
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
Res. WP5 WP4 WP3
rw rw rw
17 16
Res. Res.
1 0
WP2 WP1
rw rw
183/1830
