Chrom-Art Accelerator™ controller (DMA2D)
12.5 DMA2D registers
12.5.1 DMA2D control register (DMA2D_CR)
Address offset: 0x0000
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. CEIE CTCIE
rw
Bits 31:18 Reserved, must be kept at reset value
Bits 17:16 MODE[1:0]: DMA2D mode
Bits 15:14 Reserved, must be kept at reset value
Bit 13 CEIE: Configuration Error Interrupt Enable
Bit 12 CTCIE: CLUT transfer complete interrupt enable
Bit 11 CAEIE: CLUT access error interrupt enable
Bit 10 TWIE: Transfer watermark interrupt enable
Bit 9 TCIE: Transfer complete interrupt enable
