Flash Bank 1 Pcrop Start Address Register (Flash_Pcrop1Sr) - ST STM32L4 5 Series Reference Manual

Embedded Flash memory (FLASH)
3.7.9

Flash Bank 1 PCROP Start address register (FLASH_PCROP1SR)

Address offset: 0x24
Reset value: 0xFFFF XXXX. Register bits are loaded with values from Flash memory at
OBL.
Access: no wait state when no Flash memory operation is on going, word, half-word access.
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:16 Reserved, must be kept cleared
130/1830
Bit 12 nRST_STOP
0: Reset generated when entering the Stop mode
1: No reset generated when entering the Stop mode
Bit 11 Reserved, must be kept cleared
Bits10:8 BOR_LEV: BOR reset Level
These bits contain the VDD supply level threshold that activates/releases the
reset.
000: BOR Level 0. Reset level threshold is around 1.7 V
001: BOR Level 1. Reset level threshold is around 2.0 V
010: BOR Level 2. Reset level threshold is around 2.2 V
011: BOR Level 3. Reset level threshold is around 2.5 V
100: BOR Level 4. Reset level threshold is around 2.8 V
Bits 7:0 RDP: Read protection level
0xAA: Level 0, read protection not active
0xCC: Level 2, chip read protection active
Others: Level 1, memories read protection active
Note: Take care about PCROP_RDP configuration in Level 1. Refer to
Level 1: Read protection
28 27 26 25
Res. Res. Res.
12 11 10 9
rw rw rw rw
Bits 15:0 PCROP1_STRT: Bank 1 PCROP area start offset
PCROP1_STRT contains the first double-word of the PCROP area.
for more details.
24 23 22
Res. Res. Res.
8 7 6
PCROP1_STRT[15:0]
rw rw rw
DocID024597 Rev 5
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
rw rw rw rw
RM0351
Section :
17 16
Res. Res.
1 0
rw rw
