Goodrive300 Series VFD
Function
code
P10.23 Running time of step 10
P10.24 Multi-step speed 11
P10.25 Running time of step 11
P10.26 Multi-step speed 12
P10.27 Running time of step 12
P10.28 Multi-step speed 13
P10.29 Running time of step 13
P10.30 Multi-step speed 14
P10.31 Running time of step 14
P10.32 Multi-step speed 15
P10.33 Running time of step 15
P10.36
Simple PLC 0–7 step
P10.34
Simple PLC 8–15 step
P10.35
P05.01– Digital input function
P05.09
P06.01– Digital outnput function
P06.04
P17.00
Simple PLC and the
P17.27 current stage of the

7.14 Multi-step speed running

Set the parameters when the VFD carries out multi-step speed running. Goodrive300 series VFDs
can set 16 stage speed which can be selected by the combination code of multi-step speed terminals
1–4. They correspond to multi-step speed 0 to 15.
Name
PLC restart
ACC/DEC time
ACC/DEC time
selection
selection
Setting frequency
multi-step speed
Detailed instruction of parameters
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
0: Restart from the first stage
1:Continue to run
frequency
0x0000–0XFFFF
0x0000–0XFFFF
23:Simple PLC stop reset
24:Simple PLC pause
15: Underload pre-alarm
16:Completion of simple PLC stage
0.00Hz–P00.03
(Max. output frequency)
0–15
175
Basic operation instruction
from the stop
Default
value
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0
0000
0000
0.00Hz
