Goodrive350 series high-performance multifunction VFD
Function
code
P10.36 PLC restart mode
Acceleration/deceleration
P10.34 time of 0–7 stage of simple
Acceleration/deceleration
P10.35 time of 8–15 stage of simple
P05.01–
Digital input function
P05.09
P06.01–
Digital output function
P06.04
P17.00
P17.27 Acutal stage of simple PLC

5.5.14 Multi-step speed running

Set the parameters used in multi-step speed running. The VFD can set 16-step speeds, which are
selectable by multi-step speed terminals 1–4, corresponding to multi-step speed 0 to multi-step speed
15.
Name
PLC
PLC
Set frequency
Description
0: Restart from the first section
1: Continue running at the frequency
when interruption occurred
0x0000–0XFFFF
0x0000–0XFFFF
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
16: Simple PLC stage reached
17: Simple PLC cycle reached
0.00Hz–P00.03 (Max. output frequency)
Displays the present stage of the simple
PLC function.
-107-
Basic operation instructions
Default
value
0
0000
0000
0.00Hz
0
