P08--Enhanced Functions - INVT Goodrive350 Series Operation Manual

Goodrive350 series high-performance multifunction VFD
P08––Enhanced functions
Function
Name
code
Acceleration
P08.00
time 2
Deceleration
P08.01
time 2
Acceleration
P08.02
time 3
Deceleration
P08.03
time 3
Acceleration
P08.04
time 4
Deceleration
P08.05
time 4
Running
P08.06 frequency of
jogging
Acceleration time
P08.07
of jogging
Deceleration time
P08.08
of jogging
P08.09 Jump frequency 1 When the set frequency is within the range of jump
Jump frequency
P08.10
amplitude 1
P08.11 Jump frequency 2
Jump frequency
P08.12
amplitude 2
P08.13 Jump frequency 3
Jump frequency
P08.14
amplitude 3
Description
See P00.11 and P00.12 for detailed definitions.
Goodrive350 series VFD defines four groups of
acceleration/deceleration time, which can be
selected by multi-function digital input terminal
(P05 group). The acceleration/deceleration time of
the VFD is the first group by default.
Setting range: 0.0–3600.0s
This function code is used to define the reference
frequency of the VFD during jogging.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
Jogging acceleration time is the time needed for
the VFD to accelerate from 0Hz to Max. output
frequency (P00.03).
Jogging deceleration time is the time needed from
decelerating from Max. output frequency (P00.03)
to 0Hz.
Setting range: 0.0–3600.0s
frequency, the VFD will run at the boundary of
jump frequency.
The VFD can avoid mechanical resonance point
by setting the jump frequency, and three jump
frequency points can be set. If the jump frequency
points are set to 0, this function will be invalid.
Set frequency f
Jump
frequency 3
Jump
frequency 2
Jump
frequency 1
-186-
1/2* jump amplitude 3
1/2* jump amplitude 3
1/2* jump amplitude 2
1/2* jump amplitude 2
1/2* jump amplitude 1
1/2* jump amplitude 1
Time t
Function parameter list
Default
Modify
value
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
○
5.00Hz
○
Depends
on model
○
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.00Hz
