INVT Goodrive350 Series Operation Manual page 239

Goodrive350 series high-performance multifunction VFD
Function
Name
code
compensation of
synchronous
motor
High-frequency
superposition
P17.31 current of
synchronous
motor
P17.32 Motor flux linkage 0.0%–200.0%
Exciting current
P17.33
reference
Torque current
P17.34
reference
AC incoming
P17.35
current
P17.36 Output torque
Motor overload
P17.37
count value
Process PID
P17.38
output
Parameter
P17.39 download wrong
function code
Motor control
P17.40
mode
Description
motor
Range: -180.0–180.0
0.0%–200.0% (of the motor rated current)
Display the exciting current reference value under
vector control mode
Range: -3000.0–3000.0A
Display torque current reference value under
vector control mode
Range: -3000.0–3000.0A
Display the valid value of incoming current on AC
side
Range: 0.0–5000.0A
Display output torque value, during forward
running, positive value is motoring state, negative
value is generating state; during reverse running,
positive value is generating state, negative value is
motoring state.
Range: -3000.0Nm–3000.0Nm
0–65535
-100.0%–100.0%
0.00–99.00
0x000–0x123
Ones: Control mode
0: Vector 0
1: Vector 1
2: VF control
3: Closed-loop vector control
Tens: Control state
-230-
Function parameter list
Default
Modify
value
●
0.0%
●
0.0%
●
0.0A
●
0.0A
●
0.0A
●
0.0Nm
●
0
●
0.00%
●
0.00
●
0x000
