Goodrive350 series high-performance multifunction VFD
Function
code
P05.07
P05.08 Polarity of input terminal
P05.09
P05.10 Virtual terminal setting
P05.11
P05.12 S1 terminal switch-on delay
P05.13 S1 terminal switch-off delay
P05.14 S2 terminal switch-on delay
P05.15 S2 terminal switch-off delay
P05.16 S3 terminal switch-on delay
P05.17 S3 terminal switch-off delay
Name
Reserved
Digital filter time
2/3-wire control mode
Description
68: Enable pulse superimposition
69: Pulse decrease
70: Electronic gear selection
71: Switch to master
72: Switch to slave
73: Reset the roll diameter
74: Switch winding/unwinding
75: Pre-drive
76: Disable roll diameter calculation
77: Clear alarm display
78: Manual braking
79: Trigger forced feeding interrupt
80: Initial roll diameter 1
81: Initial roll diameter 2
82: Trigger fire mode control
83: Switch tension PID parameters
84–95: Reserved
/
0x00–0x3F
0.000–1.000s
0x00–0x3F (0: disable, 1: enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT8: HDIB virtual terminal
0: 2-wire control 1
1: 2-wire control 2
2: 3-wire control 1
3: 3-wire control 2
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
-103-
Basic operation guidelines
Default
value
/
0x00
0.010s
0x00
0
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
