Goodrive350 series high-performance multifunction VFD
Function
Name
code
Mapped function
P14.70 code of sent
PZD12
P15––Functions of communication expansion card 1
Function
Name
code
P15.00 Reserved
P15.01 Module address 0–127
Received PZD2 0–31
P15.02
P15.03 Received PZD3
P15.04 Received PZD4
P15.05 Received PZD5
P15.06 Received PZD6
P15.07 Received PZD7
P15.08 Received PZD8
P15.09 Received PZD9
P15.10 Received PZD10
P15.11 Received PZD11
P15.12 Received PZD12
Description
0x0000–0xFFFF
Description
/
0: Invalid
1: Set frequency (0–Fmax. Unit: 0.01Hz)
2: PID reference (-1000–1000, in which 1000
corresponds to 100.0%)
3: PID feedback (-1000–1000, in which 1000
corresponds to 100.0%)
4: Torque setting (-3000–+3000, in which 1000
corresponds to 100.0% of the motor rated current)
5: Setting of the upper limit of forward running
frequency (0–Fmax. Unit: 0.01 Hz)
6: Setting of the upper limit of reverse running
frequency (0–Fmax. Unit: 0.01 Hz)
7: Upper limit of electromotive torque (0–3000, in
which 1000 corresponds to 100.0% of the motor
rated current)
8: Upper limit of braking torque (0–3000, in which
1000 corresponds to 100% of the motor rated
current)
9: Virtual input terminal command (Range: 0x000–
0x3FF, corresponding to
S8/S7/S6/S5/HDIB/HDIA/S4/S3/S2/S1)
10: Virtual output terminal command (Range:
0x00–0x0F, corresponding to RO2/RO1/HDO/Y1)
11: Voltage setting (special for V/F separation)
(0–1000, in which 1000 corresponds to 100% of
the motor rated voltage)
12: AO1 output setting 1 (-1000–+1000, in which
1000 corresponds to 100.0%)
13: AO2 output setting 2 (-1000–1000, in which
-219-
Function parameter list
Default
Modify
value
○
0x0000
Default
Modify
value
/
/
◎
2
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
