INVT Goodrive350 Series Operation Manual page 66

Goodrive350 series high-performance multifunction VFD
Function
code
P03.12 Torque set through keypad
P03.13 Torque reference filter time 0.000–10.000s
Setting source of FWD
P03.14 rotation frequency upper
limit in torque control
Setting source of REV
P03.15 rotation frequency upper
limit in torque control
FWD rotation frequency
P03.16
upper limit set through
Name
3: AI2
4: AI3
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus/Modbus TCP communication
8: PROFIBUS/CANopen/DeviceNet
communication
9: Ethernet communication
10: Pulse frequency HDIB
11: EtherCAT/PROFINET/EtherNet IP
communication
12: Programmable card
Note: For these settings, 100%
corresponds to the motor rated current.
-300.0%–300.0% (of the motor rated
current)
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
Note: For these settings, 100%
corresponds to the max. frequency.
0: Keypad (P03.17)
1–11: Same as those of P03.14
Value range: 0.00 Hz–P00.03 (Max. output
frequency)
Description
-57-
Basic operation guidelines
Default
value
50.0%
0.010s
0
0
50.00Hz
