EC-PG505-24 can work in combination with multiple types of incremental encoders through various
external wiring modes. It is user-friendly, adopting spring terminals.
EC-PG505-24 terminal function description
Signal
PWR
PGND
A1+
A1-
B1+
B1-
Z1+
Z1-
A2+
A2-
B2+
B2-
Z2+
Z2-
AO
BO
ZO
Name
On: The expansion card is establishing a connection with the
control board.
Blinking periodically: The expansion card is properly
State
connected to the control board (the period is 1s, on for 0.5s,
indicator
and off for the other 0.5s).
Off: The expansion card is disconnected from the control
board.
This indicator blinks only if A1 or B1 signal is disconnected
indicator during encoder rotating; and it is on in other cases.
Power
On: The control board feeds power to the PG card.
indicator
Port
Encoder power
supply
Encoder interface
Pulse reference
Frequency-divided
output
Description
Description
Voltage: 24 V ± 5%
Max. output current: 150 mA
1. Supporting 24 V push-pull interfaces
2. Supporting 24 V open collector interfaces
3. Frequency response: 200 kHz
1. Supporting interfaces whose signal type is the
same as the encoder
2. Frequency response: 200 kHz
1. Open collector output
2. Supporting frequency division of 1–255, which
can be set through P20.16 or P24.16
