Indicator definition
The EtherNet/IP communication card provides four LED indicators and four net port indicators to
indicate its states.
Indicator Color
LED1 Green
LED2 Green
LED3 Red
LED4 Red
Net port
Yellow
indicator
Net port
Green
indicator
Electrical wiring
The EtherNet/IP communication card provides standard RJ45 ports and supports the linear, star, and
ring topologies. The following three figures show the electrical wiring diagrams.
Name
RX+
n/c
n/c
RX-
n/c
n/c
State
On
Blinking (1Hz)
Off
On
Blinking (1Hz)
Off
On
Blinking (1Hz)
Blinking (2Hz)
Blinking (4Hz)
Off
On
On
Off
On
Off
Description
Receive Data+
Not connected
Not connected
Receive Data-
Not connected
Not connected
Description
The card is shaking hands with the VFD.
The card and VFD communicate normally.
The card and VFD communicate improperly.
The communication between the card and PLC is
online and data interchange is allowed.
IP address conflict between the card and PLC.
The communication between the card and PLC is
offline.
Failed to set up I/O between the card and PLC.
Incorrect PLC configuration.
The card failed to send data to the PLC.
The connection between the card and PLC timed
out.
No fault.
3.3V power indicator.
Link indicator, indicating successful Ethernet
connection.
Link indicator, indicating Ethernet connection not
established.
ACK indicator, indicating data interchange being
performed.
ACK indicator, indicating data interchange not be
performed.
