INVT Goodrive350 Series Operation Manual page 155

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Waiting time of
P01.22 restart after
power down
P01.23 Start delay
P01.24 Stop speed delay 0.0–600.0s
Open-loop 0Hz
P01.25
output selection
Deceleration time
P01.26 of
emergency-stop
Time of starting
section of
P01.27
deceleration S
curve
Time of ending
section of
P01.28
deceleration S
curve
Short-circuit
P01.29
braking current
Hold time of
P01.30 short-circuit
braking at startup
Hold time of
P01.31 short-circuit
braking at stop
Description
This parameter specifies the waiting time before
automatically running at next power-on after power
down.
Output frequency
t1
Running
Power off
Setting range: 0.0–3600.0s (valid when P01.21=1)
This parameter specifies the delay of the VFD's
wake-up-from-sleep after running command is
given, the VFD will start to run and output after the
time set by P01.23 elapses to realize brake
release.
Setting range: 0.0–600.0s
0: No voltage output
1: With voltage output
2: Output as per DC braking current of stop
0.0–60.0s
0.0–50.0s
0.0–50.0s
When the VFD starts in direct start mode
(P01.00=0), set P01.30 to a non-zero value to
enter short-circuit brake.
During stop, if the running frequency of VFD is
below the starting frequency of braking after stop,
set P01.31 to a non-zero value to enter
short-circuit braking after stop, and then carry out
DC braking in the time set by P01.12 (refer to
-146-
t1=P01.22
t2=P01.23
t2
t
Running
Power on
Function parameter list
Default
Modify
value
○
1.0s
○
0.0s
○
0.0s
○
0
○
2.0s
◎
0.1s
◎
0.1s
○
0.0%
○
0.00s
○
0.00s
