Goodrive350 series high-performance multifunction VFD

Installation guidelines

4.2.7 Tilted installation

Figure 4-6 Tilted installation

Note: During tilted installation, it is a must to ensure the air inlet duct and air outlet duct are separated

from each other to avoid mutual interference.
