Goodrive350 series high-performance multifunction VFD
Function
Name
code
P19.15 VFD control word 0–65535
P19.16 VFD status word 0–65535
Ethernet
P19.17 monitoring
variable 1
Ethernet
P19.18
monitoring
variable 2
Ethernet
P19.19
monitoring
variable 3
Ethernet
P19.20
monitoring
variable 4
AI/AO detected
P19.21
temperature
P19.22–
Reserved
P19.39
P20––Encoder of motor 1
Function
Name
code
Encoder type
P20.00
display
Encoder pulse
P20.01
number
P20.02 Encoder direction
Description
0: No alarm
1: PT100 detected OH alarm (A-Ot1)
2: PT1000 detected OH alarm (A-Ot2)
3: PT100 disconnection alarm (A-Pt1)
4: PT1000 disconnection alarm (A-Pt2)
0–65535
0–65535
0–65535
0–65535
-20.0–200.0° C
0–65535
Description
0: Incremental encoder
1: Resolver-type encoder
2: Sin/Cos encoder
3: Endat absolute encoder
Number of pulses generated when the encoder
revolves for one circle.
Setting range: 0–60000
0x000–0x111
Ones: AB direction
0: Forward
1: Reverse
Tens: Z pulse direction (reserved)
-237-
Function parameter list
Default
Modify
value
●
0
●
0
●
0
●
0
●
0
●
0
●
0.0° C
●
0
Default
Modify
value
●
0
◎
1024
◎
0x000
