Goodrive350 series high-performance multifunction VFD
network topology or star network topology. The electrical connection in linear network topology mode
is shown in the following.
Master
device
Note: For the star network topology, you need to prepare PROFINET switches.
The electrical connection in start network topology mode is shown in the following.
Master
device
A.6.6 EtherNet/IP communication card (EC-TX510) and Modbus TCP communication card
(EC-TX515)
The communication port adopts standard dual RJ45 interfaces, and the two RJ45 interfaces are not
distinguished from each other and can be interchangeably inserted.
Standard RJ45 interface functions
Pin
1
2
Slave device 1
RJ45 RJ45
Slave device 1
RJ45
RJ45
Figure A-7 Standard RJ45 interface
Name
TX+
TX-
Slave device 2
RJ45 RJ45
Slave device 2
RJ45
RJ45
Switch
Description
Transmit Data+
Transmit Data-
-354-
Expansion cards
Slave device n
RJ45 RJ45
Slave device n
RJ45
RJ45
