Goodrive350 series high-performance multifunction VFD
Function
Name
code
start delay time Note: The SPO detection is started only after the
SPO unbalance
P11.29
factor
P11.30 Reserved
Fault severity
P11.31
group 1
Fault severity
P11.32
group 2
Fault severity
P11.33
group 3
Fault severity
P11.34
group 4
Fault severity
P11.35
group 5
Fault severity
P11.36
group 6
Fault severity
P11.37
group 7
Fault severity
P11.38
group 8
Fault severity
P11.39
group 9
Fault severity
P11.40
group 10
Fault severity
P11.41
group 11
Fault severity
P11.42
group 12
Fault severity
P11.43
group 13
Fault severity
P11.44
group 14
Fault severity
P11.45
group 15
P11.46 Fault severity
Description
VFD runs for the delay time specified by P11.28 to
advoid false alarms caused by the unstable
frequency.
0–10
/
0x0000–0x3333
Thousands place/Hundreds place/Tens
place/Ones place:
0: Report the fault
1: Report the fault after deceleration to stop
2: Pre-alarm, with the action executed according
to P11.51
3: Screen out the fault
Note: Different fault actions are taken for different
fault severities. The first 10 faults are not grouped
by severity, but each four of the subsequent faults
are grouped by severity in ascending order from
right to left in hexadecimal format, that is, from the
ones place to the thousands place (for example,
the ones place of fault severity group 1
corresponds to fault 11).
Group 1: Faults 11–14 (OL1, OL2, SPI, SPO)
Group 2: Faults 15–18 (OH1, OH2, EF, CE)
Group 3: Faults 19–22 (ItE, tE, EEP, PIDE)
Group 4: Faults 23–26 (bCE, END, OL3, PCE)
Group 5: Faults 27–30 (UPE, DNE, E-DP, E-NET)
Group 6: Faults 31–34 (E-CAN, ETH1, ETH2,
dEu)
Group 7: Faults 35–38 (STo, LL, ENC1o, ENC1d)
Group 8: Faults 39–42 (ENC1Z, STO, STL1,
STL2)
Group 9: Faults 43–46 (STL3, CrCE, P-E1, P-E2)
Group 10: Faults 47–50 (P-E3, P-E4, P-E5, P-E6)
Group 11: Faults 51–54 (P-E7, P-E8, P-E9, P-E10)
Group 12: Faults 55–58 (E-Err, ENCU, E-PN,
SECAN)
-207-
Function parameter list
Default
Modify
value
○
6
/
/
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0x0000
