INVT Goodrive350 Series Operation Manual page 162

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Torque set
P03.12
through keypad
Torque reference
P03.13
filter time
Setting source of
FWD rotation
P03.14 frequency upper
limit in torque
control
Setting source of
REV rotation
P03.15 frequency upper
limit in torque
control
Description
12: Programmable card
Note: For these settings, 100% corresponds to the
motor rated current.
-300.0%–300.0% (of the motor rated current)
0.000–10.000s
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
Note: For these settings, 100% corresponds to the
max. frequency.
0: Keypad (P03.17)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
-153-
Function parameter list
Default
Modify
value
○
20.0%
○
0.010s
○
0
○
0
