keypad in torque control
REV rotation frequency
P03.17 upper limit set through
keypad in torque control
Setting source of
P03.18 electromotive torque upper
Setting source of braking
P03.19
torque upper limit
Electromotive torque upper
P03.20
limit set through keypad
Braking torque upper limit
P03.21
set through keypad
Flux-weakening coefficient
P03.22
in constant power area
Min. flux-weakening point
P03.23
in constant power area
P03.24 Max. voltage limit
P03.25 Pre-exciting time
P03.32 Enabling torque control
Flux weakening integral
P03.33
P03.35 Control optimization setting
Name
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
limit
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
communication
10: Programmable card
11: Reserved
Note: For these settings, 100%
corresponds to the motor rated current.
0: Keypad (P03.21)
1–10: Same as those for P03.18
0.0–300.0% (of the motor rated current)
0.1–2.0
10%–100%
0.0–120.0%
0.000–10.000s
0:Disable
1:Enable
0–8000
gain
0x0000–0x1111
Ones place: Torque command selection
Description
-58-
Basic operation guidelines
Default
value
50.00Hz
0
0
180.0%
180.0%
0.3
20%
100.0%
0.300s
0
1200
0x0000
